Table 10-3. continued - Replaceable parts, RFL 9780 Output Filter modules
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
CAPACITORS -continued
C7 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.0535µF
0105 15
106530-2, -12: 0.024µF
0105 119
106530-3, -13: 0.01µF
0105 11
106530-4, -14: N/A NA
106530-5, -15: 0.014µF
0105 92
C8 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.068µF
0105 58
106530-2, -12: 0.0315µF
0105 88
106530-3, -13: 0.013µF
0105 117
106530-4, -14: N/A NA
106530-5, -15: 0.018µF
0105 83
C9 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.00535µF
0105 70
106530-2, -12: 0.0024µF
0105 106
106530-3, -13: 0.001µF
0105 103
106530-4, -14: N/A NA
106530-5, -15: 0.0014µF
0105 104
C10 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.027µF
0105 120
106530-2, -12: 0.0125µF
0105 116
106530-3, -13: 0.0051µF
0105 111
106530-4, -14: N/A NA
106530-5, -15: 0.00715µF
0105 114
C11 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.021µF
0105 118
106530-2, -12: 0.01µF
0105 11
106530-3, -13: 0.0041µF
0105 109
106530-4, -14: N/A NA
106530-5, -15: 0.0056µF
0105 112
C12 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.018µF
0105 83
106530-2, -12: 0.0082µF
0105 115
106530-3, -13: 0.00345µF
0105 108
106530-4, -14: N/A NA
106530-5, -15: 0.0047µF
0105 110
