7.3 TYPICAL CONFIGURATION SETTINGS
Table 7-1 lists some typical configuration settings for the 9780 FSK PLC. Note that these settings are
typical, and are not standard settings. Each RFL 9780 application is unique and should be carefully
evaluated by a knowledgeable Engineer. Normally, when a unit is shipped from RFL it is shipped
configured for the user's application. If, however, RFL is not aware of application specifics, the system
will be supplied with the typical settings. RFL Sales and Customer Support personnel are always
available to answer questions or assist in configuring a system.
Table 7-1. Typical Configuration Settings for 9780 DTT, PTT and DCU Applications
Function Typical Setting Switch Positions
Trip Latch Disabled SW1-1
OFF
Power Boost Level 1W/ 10W SW1-2 SW1-3 SW1-4
OFF OFF ON
Trip Override Voice Disabled SW1-5
OFF
Voice Enable Disabled SW1-6
OFF
Keying Mode 2F, Dual-Trip Keying SW1-7 SW1-8
OFF ON
Polarity Of Transmitted Trip Frequency * Trip down in frequency SW2-1
OFF
TRIPIN_1 Input Contacts ** Normally de-energized SW2-2
OFF
TRIPIN_2 Input Contacts ** Normally de-energized SW2-3
OFF
* Depends upon customer preference
** Depends upon contacts required
