16.10.7 VIEWING AN INDIVIDUAL EVENT RECORD
To view an individual record from the Directory Of Events, enter its record number. For example, to
view Record number 1, enter a "1":
9780TxRx-S>1 [ENTER]
An individual record similar to the one shown in Figure 16-16 will appear.
The individual event records shown in Figure 16-16 lists the record number, the name of the input that
changed state to trigger the event, and the date and time the event occurred. Below this, the status of all
inputs, outputs, and alarm outputs at the time of the event are listed. This information can be used to
analyze system conditions at the precise instant the event occurred.
Record 01 Event Trigger: TX Fail #1 Active
Event Time: 05/26/1999 15:54:53.385
011 Tx Fail #1 Active 013 Logic Alarm #1 Inactive
015 Power Fail #1 Inactive 016 Power Fail #2 Inactive
017 Low Level #1 Active
031 Guard Out #1 Active 033 Trip Out #1 Active
035 Trip Key #1 Inactive 036 Trip Key #2 Inactive
044 IRIG-B Status Unlocked
9780TxRx-S>
Figure 16-16. Typical individual event record
16.11 THE WINDOW REMOTE APRIL MODE
The Window Remote APRIL mode is not applicable in the RFL 9780 chassis.
