RFL 9780 RFL Electronics Inc.

April 8, 2003 17-4 (973) 334-3100

Table 17-1. RFL 9780 I/O modules Application Information

9780 Application Assembly

Number

I/O Module See the following

paragraphs for more

information

ONLY

TX/TX RX/RX TX/RX

106435-3

X 106435-4 Solid-state/Relay I/O 17.2

106435-5

106440-3

X X 106440-4 Solid-state Output I/O 17.3

106440-5

106445-3

X 106445-4 Solid-state In/Out I/O 17.4

106445-5

X X X 106470 Dual Relay I/O 17.5

X X X X 106465 Alarm Relay I/O 17.6

106600-3

X 106600-4 Input/Alarm I/O 17.7

106600-5

X 106585-1 TX/RX RF Line I/O 17.8.1.1

X 106585-2 TX/RX RF Line I/O 17.8.1.1

X 106585-3 TX/RX RF Line I/O 17.8.1.2

X 106585-4 TX/RX RF Line I/O 17.8.1.2

X 106585-5 TX/RX RF Line I/O 17.8.1.2

X 106585-6 TX RF Line I/O 17.8.1.3

X 106585-7 RX RF Line I/O 17.8.1.4

X 106585-8 TX/RX RF Line I/O 17.8.1.5

X 106585-9 TX/RX RF Line I/O 17.8.1.6

X 106590 TX/TX Line I/O 17.8.1.7

X 106605 RX/RX Line I/O 17.8.1.8

X X X 106675 External Power Amp I/O

Module

17.9
