RFL 9780 RFL Electronics Inc.
April 8, 2003 10-6 (973) 334-3100
Table 10-2. RFL 9780 Output Filter Modules, frequency ranges
Filter Module
Part No.
Jumper Position Passband Frequency Range Approximate Frequency Of
Greatest Attenuation
106530-1, -11 A 30 to 41.5 kHz 90 kHz
B 38 to 52.5 kHz 114 kHz
C 49 to 67.5 kHz 147 kHz
106530-2, -12 A 64 to 88.5 kHz 192 kHz
B 85 to 117.5 kHz 255 kHz
C 114 to 157.5 kHz 342 kHz
106530-3, -13 A 154 to 212.5 kHz 462 kHz
B 209 to 288.5 kHz 627 kHz
C 285 to 393.5 kHz 855 kHz
106530-4, -14 . . . 390 to 537.5 kHz 1170 kHz
106530-5, -15 A 114 to 157.5 kHz 342 kHz
B 154 to 212.5 kHz 462 kHz
C 209 to 288.5 kHz 627 kHz
NOTE: For proper filter operation, all seven jumpers (J1 through J7) on each Filter Module must be placed in the same
block (all in A, all in B, or all in C).
