19.3.1 CONTROLS AND INDICATORS FOR 106455-1 & -2 P.S. I/Os
Figure 19-6 shows the location of all controls on the RFL 9780 Single Power supply I/O module. These
controls are described in Table 19-6.
Table 19-6. Controls and indicators, RFL 9780 single power supply I/O module
Component
Designator
Name/
Description
Function
F1
Fuse Power supply fuse
SW1 Switch Power supply ON/OFF switch
TB1 Terminal Board Input power connections
Figure 19-6. Controls and indicators, RFL 9780 single power supply I/O module
1
0
F1
4A
ON
P.S.I/O
OFF
SB+
SB-
SW SB+
SW SB-
SW1
F1
TB
