RFL Electronics 9780 - Table 17-11. Replaceable Parts, RFL 9780 Dual Relay I;O Module

RFL 9780 RFL Electronics Inc.
April 8, 2003 17-41 (973) 334-3100
Table 17-11. Replaceable Parts, RFL 9780 Dual Relay I/O module
Assembly No. 106470
Circuit Symbol
(Figs. 17-17 & 17-18)
Description Part Number
C1-6
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C7, 8
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR3, 4 Diode, silicon, rectifier, 1A, 1N4003 30769
J1, 2, 3 Connector, header, single, 3 circuit 32802 3
K1, 2 Relay, SPST, 8A/300V, 6V/0.22W 101461
P1 Connector, plug, female, 64 contact, DIN 99134
Q1 Transistor, silicon, NPN, 2N2222A 37445
R1, 2
Resistor, metal film, axial 162Ω, 1%, 1/4W
0410 2212
R3 Resistor, metal film, axial 1K, 1%, 1/4W 0410 1288
TB1 Terminal block, 6-position 101462
J1, 2, 3 Jumper, connector, programmable, 0.1 inch centers, white 98366
