RFL Electronics 9780 - Table 17-22. Replaceable Parts, RFL 9780 External Power Amp I;O Module

RFL 9780 RFL Electronics Inc.
April 8, 2003 17-93 (973) 334-3100
Table 17-22. Replaceable Parts, RFL 9780 External Power Amp I/O module
Assembly No. 106675
Circuit Symbol
(Figs. 17-44 & 17-45)
Description Part Number
A Board
C1 Capacitor, 1.0uF, 50V 0135 51052
C2, 5, 7-11 Capacitor, 0.1uF 0120 38
C3 Capacitor, tanatlum 3.3uF 1007 1260
C4, 6 Capacitor, electrolytic 47uF 1007 1578
CR3, 6 Diode, 1N4003 30769
J1 Connector, TX 103731
JP1, 2, 5 Header, 3-pin 32802 3
JP3, 4 Header, dual, 3-position 32599 6
P1 Connector, euro, 64 pin 99134
R1, 4 Resistor, 1K 0410 1288
R7, 11
Resistor, 221Ω
0410 1225
R8, 9, 12, 13, 16, 17 Resistor, 4.75K 0410 1353
TB9 Terminal block, 4-position 101697 4
U1 Integrated circuit, OP AMP 0620 384
U2 Integrated circuit, quad NAND 0615 159
U3, 4 Integrated circuit, 6N139 29592
B Board
CR101 PO800EA 101473
E101 Spark gap 101472
J2 Connector, RX 103731
J104 SMB 101485
J105 Molex, 0.001, 4-position 95067 4
JP101 Header, dual, 3-position 32599 6
R101, 102
Resistor, fixed composition, 150Ω, 1W
1009 183
R103, 104, 105
Resistor, fixed composition, 100Ω, 1W
1009 182
