16.4 DISPLAYING APRIL HELP
To see a list of APRIL commands while the "9780>" prompt is displayed, use the "H" command.
9780>H [ENTER]
When you invoke the "H" command, the APRIL command main menu shown in Figure 16-3 will re-
appear on your screen.
16.5 VIEWING THE VALUES DISPLAY
To view the values display, enter the "V" command.
9780TxRx>V [ENTER]
The "V" command tells the RFL 9780 to send a copy of the most recently measured values to your
terminal. This display is for viewing only and cannot be changed by the user. Typical values displays
for the five different types of 9780 chassis are shown in Figures 16-4 to 16-8.
# ALARM STATUS
011 Tx Fail #1 Inactive
015 Power Fail #1 Inactive
016 Power Fail #2 Inactive
# SIGNAL STATUS
035 Trip Key #1 Inactive
036 Trip Key #2 Active
044 IRIG-B Status Unlocked
102 TxCh1 PWR (50ohm) 0.6 Watts
104 TxCh1 Actual PWR 0.3 Watts
106 TxCh1 REFL_PWR >40%
9780Tx>
Figure 16-4. Typical values display for a Tx Only operating mode
