RFL 9780 RFL Electronics Inc.
April 8, 2003 14-8 (973) 334-3100
Table 14-2. Replaceable parts, RFL 9780 Limiter/Slicer Module.
Assembly No. 106430-1, -2, -3, -11, -12, and –13
Circuit Symbol
(Figs. 14-4 & 14-5)
Description Part Number
CAPACITORS
C1, 2, 3, 15, 17 Capacitor, tantalum, 47µF, 20%, 35V 1007 1578
C4, 5, 6 Capacitor, ceramic dip, 0.01µF, 5%, 100V 1007 1645
C7-13, 51-71 Capacitor, ceramic dip, 0.1µF, 10%, 50V 0120 38
C18 Capacitor, tantalum, 0.27µF, 10%, 50V 0130 52741
C19, 30, 31 Capacitor, ceramic, 0.0068µF, 5%, 100V 0125 16825
C20, 21, 32, 33 Capacitor, ceramic, 0.47µF, +80 -20%, 50V 1007 939
C22, 26 Capacitor, ceramic, 0.068µF, 5%, 50V 1007 1831
C23, 24 Capacitor, ceramic, 0.0012µF, 5%, 50V 0125 51225
C23A, 24A, 50 Capacitor, ceramic, 100pF, 5%, 200V 0125 21015
C25, 27 Capacitor, ceramic, 0.018µF, 5%, 50V 1007 1829
C28, 29 Capacitor, ceramic, 33pF, 5%, 200V 0125 23305
C34, 36A Capacitor, ceramic, 0.0015µF, 5%, 100V 0125 11525
C34A Capacitor, ceramic, 0.033µF, 5%, 50V 1007 1830
C35 Capacitor, ceramic, 390pF, 5%, 100V 0125 13915
C35A Capacitor, ceramic, 120pF, 5%, 200V 0125 21215
C36, 37 Capacitor, ceramic, 0.0056µF, 5%, 100V 0125 15625
C38, 42, 45, 46 Capacitor, ceramic
106430-1, -2, -3: 0.027µF, 5%, 50V 1007 1834
106430-11, -12, -13: 0.033µF, 5%, 100V 1007 1830
C39, 40, 43, 44, 47, 48 Capacitor, ceramic, 27pF, 5%, 200V 0125 22705
C41 Capacitor, ceramic
106430-1, -2, -3: 0.1µF, 5%, 50V 1007 1832
106430-11, -12, -13: 0.12µF, 5%, 100V 1007 1867
C49 Capacitor, ceramic
106430-1, -2, -3: 0.012µF, 5%, 50V 0125 51235
106430-11, -12, -13: 0.015µF, 5%, 100V 0125 11535
C72 Capacitor, tantalum, 3.3µF, 20%, 35V
1007 1260
