Table 14-2. continued - Replaceable parts, RFL 9780 Limiter/Slicer Module
Circuit Symbol
(Figs. 14-4 & 14-5)
Description Part Number
RESISTORS
R1, 2 Resistor, fixed composition, 2.7Ω, 5%, 1/4W 1009 900
R3, 4, 24, 25, 96 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R5, 36, 49, 77, 83, 89 Resistor, metal film, variable, 10K, 10%, 1/2W 48548
R6, 47 Resistor, metal film, axial, 5.11K, 1%, 1/4W 0410 1356
R7, 14, 19, 46 Resistor, metal film, precision, 1M, 1%, 1/4W 0510 1813
R8, 45 Resistor, metal film, axial, 9.31K, 1%, 1/4W 0410 1381
R9, 11-13, 15-18, 20-23, Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
33, 39, 40, 44, 59,
60, 63-65, 69, 75,
97, 102
R10, 32, 35, 43, Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
82, 88, 94
R26-28, 95, 98, 99, 105 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 1192
R29 Resistor, metal film, variable, 20K, 10%, 1/2W 44529
R30 Resistor, metal film, axial
106430-1, -11: 16.9K, 1%, 1/4W 0410 1406
106430-2, -3, -12, -13: 14.3K, 1%, 1/4W 0410 1399
R31 Resistor, metal film, axial, 1.05K, 1%, 1/4W 0410 1290
R34, 37, 38, 50-52, Resistor, metal film, axial, 20K, 1%, 1/4W 0410 1413
56, 66, 67, 70-72, 74,
76, 103, 104
R41 Resistor, metal film, axial, 681K, 1%, 1/4W 0410 1560
R42 Resistor, metal film, axial, 75K, 1%, 1/4W 0410 1410
R48 Resistor, metal film, axial, 3.32K, 1%, 1/4W 0410 1338
R53, 54, 55, 61 Resistor, metal film, axial, 5.9K, 1%, 1/4W 0410 1362
R57 Resistor, metal film, axial, 5.36K, 1%, 1/4W 0410 1358
R58 Resistor, metal film, variable, 1K, 10%, 1/2W 49995
R62 Resistor, metal film, axial, 6.34K, 1%, 1/4W 0410 1365
R68, 73 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R78, 84, 90 Resistor, metal film, axial
106430-1, -2, -3: 45.3K, 1%, 1/4W 0410 1447
106430-11, -12, -13: 47.5K, 1%, 1/4W 0410 1449
R79-81 Resistor, metal film, axial
106430-1, -2, -3: 49.9K, 1%, 1/4W 0410 1451
106430-11, -12, -13: 51.1K, 1%, 1/4W 0410 1452
R85-87, 91-93 Resistor, metal film, axial
106430-1, -2, -3: 48.7K, 1%, 1/4W 0410 1450
106430-11, -12, -13: 51.1K, 1%, 1/4W 0410 1452
R106, 107 Resistor, metal film, axial, 14K, 1%, 1/4W 0410 1398
