RFL 9780 RFL Electronics Inc.
April 8, 2003 14-10 (973) 334-3100
Table 14-2. continued - Replaceable parts, RFL 9780 Limiter/Slicer Module
Circuit Symbol
(Figs. 14-4 & 14-5)
Description Part Number
SEMICONDUCTORS
CR1, 2 Diode, Schottky barrier, 1N6263 93631
CR3 Diode, Schottky, 1A, 20V, 1N5817 30150
CR4-10 Diode, silicon, 1N914B/1N4448 26482
U1 Integrated circuit, linear QUAD comparator 0620 377
U2 Integrated circuit, MOS, QUAD, 2 input AND gate 0615 161
U3, 5, 10 Integrated circuit, linear JFET OP AMP 0620 182
U4 Integrated circuit, linear dual comparator 0620 352
U6 Integrated circuit, MOS HEX inverter 0615 185
U7 Integrated circuit, MOS QUAD 2 input exclusive OR-gate 0615 268
U8 Integrated circuit, linear voltage regulator, 5V, positive 0620 204
U9 Integrated circuit, linear voltage regulator, 5V, negative 0620 210
U11-14 Integrated circuit, linear JFET OP AMP 0620 227
MISCELLANEOUS COMPONENTS
DS1 Opto device, LED, red, 5vdc 101761
DS2 Opto device, LED, red, 5vdc 101762
J1, 2 Connector, header, single, 3 circuit 32802 3
TP1 Test point, black 38116 3
TP2-11 Test point, terminal, orange 98441 3
TP12 Test point, red 38116 2
TP13 Test point, orange 38116 6
TP14 Test point, yellow 38116 8
TP15
Test point, purple 38116 10
