Table 15-5. Replaceable parts, RFL 9780 SOE/IRIG-B I/O Module Assembly No. 106475-1
Circuit Symbol
(Fig. 15-7 and 15-8)
Description Part
Number
CAPACITORS
C1, 3, 5, 7
Capacitor, ceramic, 0.001µF, 10%, 100V
0130 11021
C2, 4, 6, 8
Capacitor, ceramic disc, 0.002µF, 20%, 1000V
1007 942
C9, 11
Capacitor, ceramic disc, 0.0068µF, 20%, 1KV
1007 91
C10, 12-17
Capacitor, ceramic, 0.01µF, 10%, 100V
0130 11031
RESISTORS
R1-4
Resistor, metal film, axial, 221Ω, 1%, 1/4W
0410 1225
R5
Resistor, metal film, axial, 100Ω, 1%, 1/4W
0410 1192
SEMICONDUCTORS
CR1, 2, 7, 8 Suppressor, transient voltage, P6KE16CA 100572
CR3, 4 Suppressor, transient voltage, P6KE30CA 100576
CR5 Suppressor, voltage, DC, 5.8V, 5%, 600W 30694
CR6, 9 Suppressor, transient voltage, 1.5KE400CA 30442
CR10 Diode, Schottkey, barrier, 1N6263 93631
MISCELLANEOUS COMPONENTS
E1-6 Bead, ferrite, shield, 2-1/2 turn 103312
J1-3 Connector, header, single, 3 circuit 32802 3
J4 Connector, coaxial, BNC, bulkhead 101691
P1 Connector, plug, female, 64 contact, DIN 99134
P2 Connector, JK male, 9-pin, right angle 101106
T1 Transformer, modem, matching 95595
TP1 Test point, terminal, orange 98441 3
