RFL 9780 RFL Electronics Inc.
April 8, 2003 10-9 (973) 334-3100
Table 10-3. continued - Replaceable, RFL 9780 Output filter modules
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
CAPACITORS - continued
C13 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.043µF
0105 54
106530-2, -12: 0.018µF
0105 83
106530-3, -13: 0.0075µF
0105 73
106530-4, -14: N/A NA
106530-5, -15: 0.01µF
0105 11
C14 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.0535µF
0105 15
106530-2, -12: 0.024µF
0105 119
106530-3, -13: 0.0095µF
0105 76
106530-4, -14: N/A N/A
106530-5, -15: 0.013µF
0105 117
C15 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.0041µF
0105 109
106530-2, -12: 0.0018µF
0105 105
106530-3, -13: 750pF 0105 102
106530-4, -14: N/A N/A
106530-5, -15: 0.001µF
0105 103
C16 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.021µF
0105 118
106530-2, -12: 0.0095µF
0105 76
106530-3, -13: 0.00375µF
0105 67
106530-4, -14: N/A N/A
106530-5, -15: 0.0051µF
0105 111
C17 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.017µF
0105 47
106530-2, -12: 0.0075µF
0105 73
106530-3, -13: 0.003µF
0105 65
106530-4, -14: N/A N/A
106530-5, -15: 0.0041µF
0105 109
C18 Capacitor, polypropylene, 2%, 100V
106530-1, -11: 0.014µF
0105 92
106530-2, -12: 0.0062µF
0105 113
106530-3, -13: 0.00255µF
0105 63
106530-4, -14: N/A N/A
106530-5, -15: 0.00345µF
0105 108
