RFL 9780 RFL Electronics Inc.
April 8, 2003 10-10 (973) 334-3100
Table 10-3. continued - Replaceable parts, RFL 9780 Output Filter modules
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
CAPACITORS - continued
C19, 20
106530-11 to -15: Capacitor, electrolytic, 47µF, 20%, 16V
1007 1629
C21,22
106530-11 to -15: Capacitor, tantalum, 0.33µF, 10%, 35V
1007 1281
C23, 24, 29-43, 46, 47, 50, 51,
106530-11 to -15: Capacitor, ceramic dip, 0.1µF, 10%, 50V
0120 38
54-58, 65, 69, 72-74, 76
C25 106530-11 to -15: Capacitor, ceramic dip, 1500pF, 5%, 50V 0120 27
C26 106530-11 to -15: Capacitor, variable, ceramic, 5-25pF
C27, 28, 52, 53
106530-11 to -15: Capacitor, ceramic, 0.47µF, 20%, 50V
0135 54742
C44, 59, 63
106530-11 to -15: Capacitor, ceramic, 0.022µF, 10%, 50V
0130 52231
C45
106530-11 to -15: Capacitor, ceramic, 0.01µF, 10%, 50V
0130 5131
C48
106530-11 to -15: Capacitor, ceramic, 1µF, 20%, 50V
0135 51052
C49
106530-11 to -15: Capacitor, ceramic, 0.001µF, 10%, 100V
0130 11021
C60, 62
106530-11 to -15: Capacitor, ceramic, 0.56µF, 10%, 50V
0130 55631
C61, 64
106530-11 to -15: Capacitor, ceramic, 0.0033µF, 10%, 100V
0130 13321
C66, 71 106530-11 to -15: Capacitor, ceramic, 100pF, 5%, 200V 0125 21015
C67, 68, 70, 75
106530-11 to -15: Capacitor, tantalum, 10µF, 10%, 20V
1007 1465
RESISTORS
R1
106530-11 to -15: Resistor, metal film, axial, 140Ω, 1%, 1/4W
0410 1206
R2, 3
106530-11 to -15: Resistor, metal film, axial, 11Ω, 1%, 1/4W
0410 1100
R4 106530-11 to -15: Resistor, metal film, axial, 17.4K, 1%, 1/4W 0410 1407
R5 106530-11 to -15: Resistor, metal film, axial, 1332, 1%, 1/4W 0410 1242
R6
106530-11 to -15: Resistor, metal film, axial, 43.2Ω, 1%, 1/4W
0410 1157
R7
106530-11 to -15: Resistor, metal film, axial, 169Ω, 1%, 1/4W
0410 1214
R8, 9, 42
106530-11 to -15: Resistor, metal film, variable, 100Ω,, 10%, 1/2W
R10, 11, 15, 16, 18, 21-23, 106530-11 to -15: Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
25, 27, 37, 39, 47-52
R12, 13 106530-11 to -15: Resistor, metal film, axial, 26.7K, 1%, 1/4W 0410 1425
R14, 19, 20 106530-11 to -15: Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
R17 106530-11 to -15: Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R24 106530-11 to -15: Resistor, metal film, axial, 2.49K, 1%, 1/4W 0410 1326
R26 106530-11 to -15: Resistor, metal film, axial, 20K, 1%, 1/4W 0410 1413
R28, 30
106530-11 to -15: Resistor, metal film, axial, 511Ω, 1%, 1/4W
0410 1260
R29, 31
106530-11 to -15: Resistor, metal film, axial, 5.11Ω, 1%, 1/4W
0410 1068
R38, 40 106530-11 to -15: Resistor, metal film, axial, 28K, 1%, 1/4W 0410 1427
R41, 43-46 106530-11 to -15: Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
To Next Page
