RFL 9780 RFL Electronics Inc.
April 8, 2003 10-11 (973) 334-3100
Table 10-3. continued - Replaceable parts, RFL 9780 Output Filter modules
Circuit Symbol
(Figs. 10-3 & 10-4)
Description Part Number
INDUCTORS
L1, 2, 3 Inductor
106530-1, -11: Coil, cup core, 77.5 turns 99403 1
106530-2, -12: Coil, cup core, 52.5 turns 99403 2
106530-3, -13: Coil, cup core, 33.5 turns 99403 3
106530-4, -14: Coil, cup core, 21.5 turns 99404
106530-5, -15: Coil, cup core, 39.5 turns 99403 4
MISCELLANEOUS COMPONENTS
CR1, 2, 3 Diode, silicon, 1N914B/1N4448 26482
CR4-7 Diode, Surmetic, rectifier, 1N4001 38876
CR8, 9 Diode, Schottky, barrier, 1N6263 93631
K1 Relay, 4PDT, 12Vdc 95282
J1-7 Connector , header, dual, 3/6 CKT 32599 6
J8 Connector, wafer assy, 4 CKT 97223 4
P1 Connector, JK male, 64 contact, DIN 98457
T1 Transformer., meter power 106531
TP1 Test point, brown 38116 4
TP2 Test point, blue 38116 7
TP3 Test point, white 38116 1
TP4 Test point, red 38116 2
TP5 Test point, orange 38116 6
TP6 Test point, yellow 38116 8
TP7 Test point, purple 38116 10
TP8 Test point, black 38116 3
TP9-13 Test point, terminal orange 98441 3
U1 Integrated Circuit, linear voltage regulator, 5V pos 0620 204
U2 Integrated Circuit, linear voltage regulator, 5V neg 0620 210
U3-8 Integrated Circuit, linear OP AMP 0620 384
U10, 12, 13 Integrated Circuit, linear precision OP AMP 0620 322
U15, 17 Integrated Circuit, linear voltage comparator 0620 395
U16, 18 Integrated Circuit, analog multiplexer 0620 491
