9780 TX/TX MOTHERBRD W/ RPM
ECB NO 106558-2 REV-A
LOGIC #1 XMT #1 OUT. FILT. #1 HYBRID #1 LOGIC #2 XMIT #2 HYBRID #2 OUT. FILT. #2 P/S #2 P/S #1
RFL ELECTRONICS INC., BOONTON, NJ, U.S.A.
SOE
Figure 20-4. Component locator drawing, RFL 9780 Rx/Rx Motherboard (Assembly No. 106555-2)
