RFL Electronics 9780 - Page 197

RFL 9780 RFL Electronics Inc.
April 8, 2003 12-9 (973) 334-3100
Table 12-3. – continued. Replaceable parts, RFL 9780 IF/BF Module
Assembly No. 106495
Circuit Symbol
(Figs. 12-4 & 12-5)
Description Part
Number
RESISTORS - continued
R17, 22, 23 Resistor, metal film, axial, 100K, 1%, 1/4W 0410 1480
R18 Resistor, metal film, axial, 27.4K, 1%, 1/4W 0410 1426
R19 Resistor, metal film, axial, 47.5K, 1%, 1/4W 0410 1449
R20 Resistor, metal film, axial, 3.01K, 1%, 1/4W 0410 1334
R21
Resistor, metal film, axial, 221Ω, 1%, 1/4W
0410 1225
R28 Resistor, variable, ceramic, 5K, 10%, 1/4W 32995
R29 Resistor, metal film, axial, 1.58K, 1%, 1/4W 0410 1307
R34 Resistor, metal film, axial, 11K, 1%, 1/4W 0410 1388
R35, 45 Resistor, metal film, axial, 10K, 1%, 1/4W 0410 1384
R36, 38
Resistor, metal film, axial, 100Ω, 1%, 1/4W
0410 1192
R37 Resistor, metal film, axial, 18.7K, 1%, 1/4W 0410 1410
R39 Resistor, metal film, axial, 5.11K, 1%, 1/4W 0410 1356
R41, 42
Resistor, fixed composition, 2.2Ω, 5%, 1/2W
1009 1059
R44 Resistor, metal film, axial, 10.0M, 1%, 1/4W 0410 1672
R46
Resistor, metal film, axial, 787Ω, 1%, 1/4W
0410 1278
R47
Resistor, metal film, axial, 121Ω, 1%, 1/4W
0410 1200
R48
Resistor, metal film, axial, 10Ω, 1%, 1/2W
0410 2096
R49, 54
Resistor, metal film, axial, 47.5Ω, 1%, 1/4W
0410 2161
R50 Resistor, metal film, axial, 2.43K, 1%, 1/4W 0410 1325
R51
Resistor, metal film, axial, 590Ω, 1%, 1/4W
0410 1266
R52
Resistor, metal film, axial, 113Ω, 1%, 1/4W
0410 1197
R53
Resistor, metal film, axial, 665Ω, 1%, 1/4W
0410 1271
R55
Resistor, metal film, precision, 249Ω, 1%, 1/2W
0410 2230
SEMICONDUCTORS
CR1, 2 Diode 32509
Q1 Transistor, silicon, NPN, 2N918 46541
U1, 6, 7 IC, linear, mixer, AD831AP 0620 380
U2 IC, linear, opamp, EL2044CN 0620 384
U3 IC, MOS, synthesizer 0615 198
U4 IC, ECL, voltage controlled oscillator 0690 3
U5 IC, MOS, dual 4-bit decade counter 0615 252
U8 IC, linear, opamp, LM318N 0620 126
U9 IC MOS, Xilinx, XC9536 Contact factory
U10 IC, linear, voltage regulator, 5V 0620 341
U11 IC, linear, voltage regulator, 5V 0620 222
U12 IC, linear, JFET, opamp 0620, 227
U13 IC, linear, voltage regulator, 8V, pos 0620 385
