RFL 9780 RFL Electronics Inc.
April 8, 2003 12-10 (973) 334-3100
Table 12-3. – continued. Replaceable parts, RFL 9780 IF/BF Module
Assembly No. 106495
Circuit Symbol
(Figs. 12-4 & 12-5)
Description Part
Number
MISCELLANEOUS COMPONENTS
FL101 Filter, crystal, 5.12mHz 32523 2
J1,2 Connector, wafer assembly, 5 ckt 42082 5
J3 Connector, header, single, 7 circuit 32802 7
L1
Inductor, molded, 220µH, 5%
46598
L2-4, 7-9
Inductor, molded, 33µH, 130 ma
32868
L5 Shielded inductor assembly 96955
L6
Inductor, molded, 100µH, 10%, 84 madc
32505 1
SW1 DIP switch, SPST, 4 position, 8 pin 98492
SW2 DIP switch, SPST, 8 position, 16 pin 98493
TP1 Test point, black 38116 3
TP2, 4-19 Test point, terminal, orange 98441 3
TP3 Test point, brown 38116 4
Y1 Crystal, 5.12 mHz 93637
Y2 Crystal, 7.8 mHz 99215 17
