Table 19-3. Replaceable parts, RFL 9780 Power Supply module (continued)
Circuit Symbol
(Figs. 19-2 & 19-3)
Description Part Number
RESISTORS - continued
R20 Resistor, metal film, axial, 332Ω, 1%, 1/4W 0410 1242
R21, 25, 33 Resistor, metal film, axial, 1.4K, 1%, 1/4W 0410 1302
R22 Resistor, metal film, axial, 154Ω, 1%, 1/4W 0410 1210
R23 Resistor, metal film, axial, 449Ω, 1%, 1/4W 0410 2259
R24, 29, 30, 36, Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
54, 63, 64
R26 Resistor, wirewound, 0.01Ω, 1%, 3W 1100 840
R27, 28 Resistor, metal oxide, 1K, 5%, 2W 1510 2368
R31, 65 Resistor, metal film, axial, 274Ω, 1%, 1/4W 0410 1234
R32, 47 Resistor, metal film, axial, 118Ω, 1%, 1/4W 0410 1199
R34, 45 Resistor, metal oxide, 56Ω, 5%, 1W 1510 2371
R35 Resistor, metal film, axial, 23.7Ω, 1%, 1/4W 0410 1132
R41 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R43 Resistor, metal film, axial, 1.07K, 1%, 1/4W 0410 1291
R44 Resistor, metal film, variable, 100Ω, 10%, 1/2W 96706
R48 Resistor, metal film, axial, 499Ω, 1%, 1/4W 0410 1259
R49, 50 Resistor, metal film, variable, 20Ω, 20%, 1/2W 105412
R51 Resistor, metal film, axial, 100Ω, 1%, 1/4W 0410 2192
R52 Resistor, metal film, axial, 2.74K, 1%, 1/4W 0410 1330
R53 Resistor, metal film, axial, 475Ω, 1%, 1/4W 0410 1257
R55 Resistor, fixed composition, 22Ω, 5%, 1/4W 1009 613
R56 Resistor, metal film, axial, 7.68K, 1%, 1/4W 0410 1373
R57, 59, 61 Resistor, metal film, axial, 2.49K, 1%, 1/4W 0410 1326
R58 Resistor, metal film, axial, 10.5K, 1%, 1/4W 0410 1386
R60 Resistor, metal film, axial, 13KΩ, 1%, 1/4W 0410 1395
R62 Resistor, metal film, precision, 10Ω, 1%, 1/4W 1510 1015
R66 Resistor, metal film, axial, 2K, 1%, 1/4W 0410 1317
SEMICONDUCTORS
CR1 Diode, rectifier, silicon, 3A, 1N5406 101716
CR2 Diode, rectifier, ultrafast, MUR8100E 105011
CR3, 4 Doide, fast recovery, 1A, 400V 103484
CR5 Diode, Zener, 13V, 5%, 1N964B 34652
CR6, 16,17 Diode, Schottky, 1A, 40V, 1N5819 103382
CR7, 8, 10, 11 Diode, rectifier, ultrafast, MUR420 103357
