18.2.3 CONTROLS AND INDICATORS
Figure 18-2 shows the location of all controls and indicators on the RFL 9780 X-Hybrid Module. These
controls and indicators are described in Table 18-1. Only TP5, TP6, TP7 and TP8 are accessible with
the X-Hybrid Module installed in the chassis. All others are accessible when the module is removed
from the chassis or is on a card extender.
P1
L2
TP4
J1
R14 R13
F1
L1
TP3
TP5
TP6
TP7 TP8
J4 J5
9780/85 HYBRID ECB NO. 106623 REV-A
DUAL SINGLE
2000 RFL ELECTRONICS INC., BOONTON, NJ, U.S.A.
TX1 RX
E C N A L A B
HI LOLOHI
32
AC
1
1
1
1
1
TP4
TP3
J1
TP8
TP
7
TP6
TP5
Figure 18-2. Controls and indicators, RFL 9780 X-Hybrid Module
