Table 6-21. continued, Replaceable parts, RFL 9780 Logic Module
Assembly No. 106490
Circuit Symbol
(Figs. 6-7 & 6-8)
Description Part Number
SEMICONDUCTORS
CR2, 7 Diode, silicon, 1N914B/1N4448 26482
CRZ1-8 Diode array, 8-diode, common cathode 103444
U1 Integrated circuit, linear QUAD comparator 0620 377
U2 Integrated circuit, linear JFET OP-AMP 0620 227
U3, 5, 6, 9 Integrated circuit, MOS 0615 297
U4 Integrated circuit, MOS HEX inverter, Schmitt trigger 0615 242
U7 Transistor array, ULN2803A 0720 7
U8 Integrated circuit, MOS field programmable gate array 0615 473
U10 Integrated circuit, MOS tri-state octal buffer 0615 176
MISCELLANEOUS COMPONENTS
DS-1 Opto device, LED, green
99799
DS2-8 Opto device, LED, red 98534
J1 Connector, header, single, 3-circuit 32802 3
L1
Inductor, coated, 100µH, 10%
103472
P1 Connector, plug, male, 96 connections, DIN 101681
SW1-8 Switch, DIP, SPST, 8-position, 16-pin 98493
SW9 Switch, SPDT, right angle, pc board mounting 98488
TP1-16 Test point, terminal, orange 98441 3
Y1 Crystal, hybrid, clock oscillator, 3.584Mhz 103347
