RFL 9780 RFL Electronics Inc.
April 8, 2003 13-15 (973) 334-3100
Table 13-4. - continued. Replaceable parts, RFL 9780 Carrier Level Indicator Module
Assembly No. 106485-6
Circuit Symbol
(Fig. 13-4 & 13-5)
Description Part Number
RESISTORS – continued
R37
Thermistor, resistor, 1000Ω, 1%
91529
R38 Resistor, metal film, axial, 2.21K, 1%, 1/4W 0410 1321
R39 Resistor, metal film, axial, 1.5M, 1%, 1/4W 0410 1593
R40 Resistor, metal film, axial, 1.21M, 1%, 1/4W 0410 1584
R41 Resistor, metal film, axial, 4.12K, 1%, 1/4W 0410 1347
R42, 85 Resistor, metal film, axial, 48.7K, 1%, 1/4W 0410 1450
R49 Resistor, metal film, axial, 4.75K, 1%, 1/4W 0410 1353
R51, 61 Resistor, metal film, axial, 4.99K, 1%, 1/4W 0410 1355
R53 Resistor, metal film, axial, 11.5K, 1%, 1/4W 0410 1390
R55 Resistor, metal film, axial, 2.49K, 1%, 1/4W 0410 1326
R57, 68, 74, 78, 80, 97, 98 Resistor, metal film, axial, 1K, 1%, 1/4W 0410 1288
R58 Resistor, metal film, variable, 25K, 10%, 3/4W 45829
R59, 62 Resistor, metal film, axial, 2K, 1%, 1/4W 0410 1317
R60 Resistor, metal film, axial, 39.2K, 1%, 1/4W 0410 1441
R63 Resistor, metal film, axial, 475K, 1%, 1/4W 0410 1545
R65 Resistor, metal film, axial, 5.36K, 1%, 1/4W 0410 1358
R71, 82 Resistor, metal film, axial, 100K, 1%, 1/4W 0410 1480
R72, 81, 83 Resistor, metal film, axial, 1.5K, 1%, 1/4W 0410 1305
R73 Resistor, metal film, variable, 50K, 10%, 1/2W 93667
R75 Resistor, metal film, axial, 95.3K, 1%, 1/4W 0410 1478
R76 Resistor, metal film, variable, 20K, 10%, 1/2W 44529
R77 Resistor, metal film, axial, 9.09K, 1%, 1/4W 0410 1380
R86 Resistor, metal film, axial, 29.4K, 1%, 1/4W 0410 1429
R87 Resistor, metal film, axial, 61.9K, 1%, 1/4W 0410 1460
R88 Resistor, metal film, axial, 16.2K, 1%, 1/4W 0410 1404
R89 Resistor, metal film, axial, 3.01K, 1%, 1/4W 0410 1334
R92
Resistor, metal film, axial, 422Ω, 1%, 1/4W
0410 1252
R93
Resistor, metal film, axial, 261Ω, 1%, 1/4W
0410 1232
R94
Resistor, metal film, axial, 316Ω, 1%, 1/4W
0410 1240
R99
Resistor, metal film, axial, 499Ω, 1%, 1/4W
0410 1259
SEMICONDUCTORS
CR1, 2, 3, 8, 9 Diode, silicon, 1N914B/1N4448 26482
CR4 Diode, general purpose, 1N4148 101778
CR6 Integrated circuit, voltage reference diode, 2.5V, 1.5% 0620 218
CR7 Diode, Zener, 5.1V, 500mw, 1N5231B 35027
Q1 Transistor, silicon, NPN, 2N2915 17128
Q2 Transistor, VMOS, FET, VN10KM 0715 13
U1 Integrated circuit, linear, QUAD, op-amp 0620 386
U2, 3 Integrated circuit, linear, JFET, op-amp 0620 182
U4, 5, 7, 8 Integrated circuit, linear, JFET, op-amp 0620 227
U6 Integrated circuit, MOS, HEX inverter 0615 271
U9 Integrated circuit, linear, precision op-amp 0620 322
