# ALARM STATUS
011 Tx Fail #1 Inactive
012 Tx Fail #2 Inactive
015 Power Fail #1 Inactive
016 Power Fail #2 Inactive
# SIGNAL STATUS
035 Trip Key #1 Inactive
036 Trip Key #2 Inactive
037 Trip Key #3 Inactive
038 Trip Key #4 Inactive
044 IRIG-B Status Unlocked
102 TxCh1 PWR(50ohm) 0.4 Watts
103 TxCh2 PWR(50ohm) 0.0 Watts
104 TxCh1 Actual PWR 0.4 Watts
105 TxCh2 Actual PWR 0.0 Watts
106 TxCh1 REFL_PWR 0.6 Watts
107 TxCh1 REFL_PWR N/A
9780TxTx>
Figure 16-7. Typical values display for a TxTx operating mode
# ALARM STATUS
013 Logic Alarm #1 Inactive
014 Logic Alarm #2 Inactive
015 Power Fail #1 Inactive
016 Power Fail #2 Inactive
017 Low Level #1 Active
018 Low Level #2 Active
# SIGNAL STATUS
031 Guard Out #1 Active
033 Guard Out #2 Active
033 Trip Out #1 Active
034 Trip Out #2 Active
044 IRIG-B Status Unlocked
100 RxCh1 Level <-10dB
101 RxCh2 Level 2.5dB
9780RxRx>
Figure 16-8. Typical values display for an RxRx operating mode
