Table 17-4. Replaceable Parts, RFL 9780 Solid State Relay I/O module
Assembly No. 106435-5
Circuit Symbol
(Figs. 17-4 & 17-6)
Description Part Number
C1-7
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C8, 11-15, 17
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
C9, 10
Capacitor, ceramic, 0.47µF, 10%, 16V
151 10474020603
C16
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR1, 2 Diode, general purpose, 1N4148 340 100
CR3 Diode, silicon, rectifier, 1A, 1N4003 30769
CR4, 5 Suppressor, voltage, 6.8V, 5%, 600W, BIDIR 101497
K1 Relay, SPST, 8A/300V, 6V/0.22W 101461
L1-4
Inductor, 10µH, 5%, 1.5A max
30285
P1 Connector, plug, female, 64 contact, DIN 99134
R1, 2, 21, 22 Resistor, thick film, 1.21K, 1%, 1/8W 700 15121134
R3, 4 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R17
Resistor, metal film, axial, 162Ω, 1%, 1/2W
0410 2212
R20
Resistor, thick film, 10Ω, 1%, 1/8W
700 1510R034
T1
Transformer, 2:1, 900µH
910 00100
TB1 Terminal block, 7 position 101463
U1, 2 Opto isolator, optical isolator, 74OL6010 101498
U3 Integrated Circuit, 3-St Quad Buffer, 74ABT125 500 101
U5 Integrated Circuit, Linear transformer driver, MAX845 510 107
U6 Integrated Circuit, Linear voltage regulator, 5V, POS 0620 204
