RFL Electronics 9780 - Page 291

RFL 9780 RFL Electronics Inc.
April 8, 2003 17-21 (973) 334-3100
Table 17-6. Replaceable Parts, RFL 9780 Solid State Output I/O module
Assembly No. 106440-5
Circuit Symbol
(Figs. 17-7 & 17-8)
Description Part Number
C101, 102 Capacitor, ceramic, 4700pF, 5%, 50V 151 05472040507
C103-106
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C111, 114,135-137,
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
139
C112, 113
Capacitor, ceramic, 0.47µF, 10%, 16V
151 10474020603
C133, 134
Capacitor, ceramic, 0.01µF, 10%, 50V
151 10103040603
CR101, 102 Diode, general purpose, 1N4148 340 100
CR103, 104 Suppressor, voltage, 6.8V, 5%, 600W BIDIR 101497
JP101, 102 Connector header, single, 2-CKT 32802 2
L101-104
Inductor, 12µH, 4.5A, 10%
30436
P1 Connector, plug, female, 64 contact, DIN 99134
Q103, 105 Transistor, silicon, NPN, medium power 105421
Q104, 106 Transistor, silicon, PNP, medium power 103384
R101, 102, 105, 106
Resistor, thick film, 432Ω, 1%, 1/8W
700 15432034
R103, 104 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R107,109 Resistor, thick film, 2K, 1%, 1/8W 700 15200134
R108, 110-112
Resistor, thick film, 562Ω, 1%, 1/8W
700 15562034
T101
Transformer, 2:1, 900µH
910 00100
TB1 Terminal block, 4 terminal 101126
U101 Integrated Circuit, MOS D RTRG MNST MV, 74HC123 500 104
U102, 103 Opto isolator, 6N139 29592
U104 Integrated Circuit, linear xformer driver, MAX845 510 107
U105, 110 Integrated Circuit, linear voltage regulator, 5V POS 0620 204
