Table 17-9. Replaceable Parts, RFL 9780 Solid-State Input/Output I/O module
Assy No. 106445-5
Circuit Symbol
(Figs. 17-14 & 17-15)
Description Part Number
Input Board Components
C1-7
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C8, 11-15, 17
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
C9, 10
Capacitor, ceramic disc, 0.47µF, 10%, 16V
151 10474020603
C16
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR1, 2 Diode, general purpose, 1N4148 340 100
CR3 Diode, silicon, rectifier, 1A, 1N4003 30769
CR4, 5 Suppressor, voltage, 6.8V, 5%, 600W, BIDIR 101497
J8 Connector, wafer assembly, 6-CKT 97223 6
K1 Relay, SPST, 8A/300V, 6V/0.22W 101461
L1-4
Inductor, 10µH, 5%, 1.5A max
30285
P1 Connector, plug, female, 64 contact, DIN 99134
R1, 2, 21, 22 Resistor, thick film, 1.21K, 1%, 1/8W 700 15121134
R3, 4 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R17
Resistor, metal film, axial, 162Ω, 1%, 1/2W
0410 2212
T1
Transformer, 2:1, 900µH
910 00100
TB1 Terminal block, 7 position 101463
TB2 Terminal block, 4 terminal 101126
U1, 2 Opto isolator, 74OL6010 101498
U3 Integrated circuit, MOS 3-ST QUAD BUF, 74ABT125 500 101
U5 Integrated circuit, linear transformer driver, MAX845 510 107
U6 Integrated circuit, linear voltage regulator, 5V POS 0620 204
Output Board Components
C101, 102 Capacitor, ceramic, 4700pF, 5%, 50V 151 05472040507
C103-106
Capacitor, ceramic disc, 0.01µF, 20%, 3KV
1007 1811
C111, 114, 135-137,
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
139
C112, 113
Capacitor, ceramic, 0.47µF, 10%, 16V
151 10474020603
C133, 134
Capacitor, ceramic, 0.01µF, 10%, 50V
151 10103040603
CR101, 102 Diode, general purpose, 1N4148 340 100
CR103, 104 Suppressor, voltage, 6.8v, 5%, 600w, bidir 101497
J108 Connector, wafer assembly, 6-CKT 97223 6
L101-104
Inductor, 12µH, 4.5A, 10%
30436
Q103, 105 Transistor, silicon, NPN, medium power 105421
Q104, 106 Transistor, silicon, PNP, medium power 103384
R101, 102, 105, 106
Resistor, thick film, 432Ω, 1%, 1/8W
700 15432034
R103, 104 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R107, 109 Resistor, thick film, 2K, 1%, 1/8W 700 15200134
R108, 110-112
Resistor, thick film, 562Ω, 1%, 1/8W
700 15562034
T101
Transformer, 2:1, 900µH
910 00100
U101 Integrated circuit, MOS D RTRG MNST MV, 74HC123 500 104
U102, 103 Opto device, 6N139 29592
U104 Integrated circuit, linear transformer driver, MAX845 510 107
U105, 110 Integrated circuit, linear voltage regulator, 5V POS 0620 204
