Table 17-15. Replaceable Parts, RFL 9780 Input/Alarm I/O module
Assembly No. 106600-5
Circuit Symbol
(Figs. 17-25 & 17-26)
Description Part Number
C1-7
Capacitor, ceramic disc, 0.01µF, 20%, 3kV
1007 1811
C8, 11-15, 17
Capacitor, ceramic, 0.1µF, 10%, 50V
151 10104040603
C9, 10
Capacitor, ceramic, 0.47µF, 10%, 16V
151 10474020603
C16
Capacitor, electrolytic, 100µF, 20%, 25V
1007 1630
CR1, 2 Diode, general purpose, 1N4148 340 100
CR3 Diode, silicon rectifier, 1A, 1N4003 30769
CR4, 5 Suppressor, voltage, 6.8V, 5%, 600W, BIDIR 101497
J1 Connector, wafer assembly, 6-CKT 97223 6
J8 Connector, wafer assembly, 6-CKT 97223 6
K1 Relay, SPST, 8A/300V, 6V/0.22W 101461
L1-4
Inductor, 10µH, 5%, 1.5A MAX
30285
P1 Connector, plug, female, 64 contact, DIN 99134
R1, 2, 21, 22 Resistor, thick film, 1.21K, 1%, 1/8W 700 15121134
R3, 4 Resistor, thick film, 10K, 1%, 1/8W 700 15100234
R17
Resistor, metal film, axial, 162Ω, 1%, 1/2W
0410 2212
R20
Resistor, thick film, 10Ω, 1%, 1/8W
700 1510R034
T1
Transformer, 2:1, 900µH
910 00100
TB1 Terminal block, 7-position 101463
TB2 Terminal block, 6-position 101462
U1, 2 Opto-isolator, 74OL6010 101498
U3 Integrated circuit, MOS 3-ST QUAD BUF, 74ABT125 500 101
U5 Integrated circuit, linear transformer driver 510 107
U6 Integrated circuit, linear voltage regulator, 5V POS 0620 204
C101-106
Capacitor, ceramic disc, 0.01µF, 20%, 3kV
1007 1811
CR101, 102 Diode, silicon rectifier, 1A, 1N4003 30769
K101, 102 Relay, DPDT, 12V, PCB mount 101718
L101-106
Inductor, 10µH, 5%, 1.5A max
30285
