Table 19-4. Replaceable parts, RFL 9780 Power Supply module (continued)
Circuit Symbol
(Fig. 19-4 & 19-5)
Description Part Number
SEMICONDUCTORS - continued
CR9 Diode, rectifier, ultrafast 105416
CR13, 20 Diode, general purpose, 1N4148 101778
CR14, 21 Diode, rectifier, ultrafast, 8A, 400V 101464
CR15, 18
Diode, rectifier, Schottky, 5A, 40V
105413
CR19 Diode, rectifier, Schottky, 30A, 45V 105417
CR22 Diode, Schottky barrier, SB160 96365
Q1, 2 Transistor, MOSFET, N-CH, 1XFH13N90 0715 43
Q3 Transistor, MOSFET, N-CH, MTP6N60E 0715 42
Q4, 7 Transistor, silicon, PNP 103384
Q5 Transistor, silicon, NPN 105421
Q6, 9 Transistor, silicon, NPN, 2N2222A 37445
Q8 Transistor, silicon, PNP, 2N2907A 37439
U1 Integrated circuit, linear, current mode, PWM 0620 326
U2 Optocoupler, HCNW136 105041
U3 Integrated circuit, linear, mag amp controller 0620 370
U4, 5 Optodevice, photo, ISO, 4N35 47104
U6, 7 Integrated circuit, linear voltage regulator, positive, 3-terminal 0620 207
U8 Integrated circuit, linear voltage regulator, negative, 3-terminal 0620 333
U9 Integrated circuit, linear, quad, fault monitor 0620 325
MISCELLANEOUS COMPONENTS
DS1 Optodevice, single LED, green 99799
L2 Choke, bias, 20 mH, 50 mAdc 105428
L3 Choke, multi-output, custom 101477
P1 Connector, JK male, 64 contact, DIN 98457
T1 Transformer, FWD, 250 Vdc 101488
TH1
Thermistor, NTC, 10Ω @ 25
o
C
105021
TP1-5 Test point terminal, orange 98441 3
