NOTE
Throughout this manual, specific terminal block terminals, DIP switch sections, and IC pin
numbers are noted by the circuit symbol number followed by a dash and the terminal, section,
or pin number (TB1-1, SW1-1, IC1-1, etc).
The circuit boards in the RFL 9780 use DIN 41612 Type C connectors, which contain columns
of 32 pins. All modules have pins in columns A and C and provide a total of 64 pins per
connector. In addition to this, the Logic Module has pins in column B giving an additional 32
pins for a total of 96 pins. Note that the pins extend from the front to the back of the unit into
the I/O Module connector.
The I/O connector pins are a mirror image of the front connector pins. In order to clarify signal
flow, the signal on pin 1 of a front module goes directly through the mother board to pin 1 of
the rear module, as marked on the rear module circuit board. Note, however, that this may not
be marked as pin 1 on the housing of the rear module’s connector.
