RFL 9780 RFL Electronics Inc.
April 8, 2003 20-4 (973) 334-3100
Table 20-3. Replaceable parts, RFL 9780 Tx/Rx Motherboard
Assembly No. 106560-2
Circuit Symbol
(Figs. 20-3 & 20-9)
Description Part Number
C1, 2, 16-24
C4-7
C8-15
J1, 5-7, 9-11, 13
J2-4
J8, 12
J15
J16, 19, 20, 27
J17, 18
J22, 23, 25, 26
J28
Capacitor, ceramic disc, 0.1µF, 10%, 100V
Capacitor, electrolytic, 1000µF, 20%, 10V
Capacitor, electrolytic, 470µF, 20%, 25V
Connector, JK, female, 64 contact, DIN
Connector, JK, female, 64 contact, DIN
Connector, JK, female, 96 contact, DIN
Connector, header, dual, 3/6 circuit
Connector, receptacle, SMB
Connector, wafer assembly, 2 circuit
Connector, header, single, 3 circuit
Connector, header, single, 2 circuit
0130 11041
1007 1746
1007 1856
101280 1
101281 1
101679 1
32599 6
101485
97223 2
32802 3
32802 2
