Ricoh S-C3 F

The pipeline clock frequency rate is
different from the prescribed value.
• Defective CPU devices
• Mode bit data error, which is used for
initializing CPU.
1. Replace the controller board.
B
[0702]: Detailed error code
The result when the program is
executed in the command cache is
different from desirable value.
• Insufficient CPU cache
• Insufficient memory process speed
1. Replace the controller board.
2. Replace the RAM DIMM.
B
[0709, 070A]: Detailed error code
Even you write the data in the only
cache of memory, the data is actually
written in another area (not cache) of
memory.
• Defective CPU devices
• Incorrect SPD
• Boot mode setting error
1. Replace the controller board.
2. Replace the RAM DIMM.
B
[0801, 0804, 0807, 0808, 0809, 80A]: Detailed error code
An error occurs when checking the TLB.
• Defective CPU devices
1. Replace the controller board.
B
[4002-4005]: Detailed error code
The calculation error in the CPU occurs.
• Defective CPU
1. Replace the CPU.
821 Self-Diagnostic Error: ASIC
[0B00] B
ASIC error
The write-&-verify check error has
occurred in the ASIC.
• Defective controller board
1. Replace the controller.
[0B06] B
ASIC not detected
The ASIC of the I/O is not detected.
• ASIC (controller board defective)
• Poor connection between North
Bridge and PCI I/F.
Service Call Conditions
121
4
