4623 SBU Offset-Result
4623 1 EVEN
[0 to 255 / 0 / 1 /step]
Displays the result value of the offset adjustment in the
SBU.
4623 2 ODD
4623 3 RED
4623 4 GREEN
4623 5 BLUE
4628 SBU Gain-Result
4628 1 EVEN
[0 to 255 / 0 / 1 /step]
Displays the result value of the gain adjustment in the SBU.
4628 2 ODD
4628 3 RED
4628 4 GREEN
4628 5 BLUE
4640 SBU Offset-Loop
4640 1 EVEN
[0 to 10 / 0 / 1 /step]
Displays the number of the offset adjustment in the SBU.
4640 2 ODD
4640 3 RED
4640 4 GREEN
4640 5 BLUE
4641 SBU Gain-Loop
4641 1 EVEN
[0 to 10 / 0 / 1 /step]
Displays the number of the gain adjustment in the SBU.
4641 2 ODD
4641 3 RED
4641 4 GREEN
4641 5 BLUE
