4013 Scanner Free Run
4013 1 Conducts the scanner free run with the exposure lamp on.
4015* White Plate Scanning
4015 1
Start position [–3.0 to +6.0 / 0.0 / 0.1 mm/step]
Adjusts the scanning start position on the white plate. The base value is 17.8 mm from the
scanner home position. This SP specifies the offset from this base value.
4015 2
Scanning length [–3.0 to +6.0 / 0.0 / 0.1 mm/step]
Adjusts the distance of the white plate scan. The scan begins from the start position
(SP4-015-001) and ends at the specified distance. The base value is 2.0 mm. This SP
decides the offset from this base value. Specify 0 (zero) or a larger value.
4428 Scan Auto Adjustment
4428 1
Conducts the automatic scanner adjustment. Use this SP after replacing the white plate
(* "Scanning" in the section "Replacement and Adjustment").
4606 SBU Offset-Target
4607 1 EVEN
[0 to 63 / 10 / 1 /step]
Adjusts the target black level for each signal.
These are used for offset adjustment in the SBU.
4607 2 ODD
4607 3 RED
4607 4 GREEN
4607 5 BLUE
4607 SBU Gain-Target
4607 1 EVEN
[0 to 255 / 180 / 1 /step]
Adjusts the target white level for each signal.
These are used for gain adjustment in the SBU.
4607 2 ODD
4607 3 RED
4607 4 GREEN
4607 5 BLUE
Service Program
143
