4658 5 BLUE
4685* Gray Balance-Book
4685 1 RED
[128 to 383 / 256 / 1 /step]
Adjusts the coefficient of the gray balance adjustment for
the book scanning.
4685 2 GREEN
4685 3 BLUE
4686* Gray Balance-DF
4686 1 RED
[128 to 383 / 256 / 1 /step]
Adjusts the coefficient of the gray balance adjustment for
the DF scanning.
4686 2 GREEN
4686 3 BLUE
4687* White Balance
4687 1 Adjust
[222 to 281 / 256 / 1 /step]
Adjust the correction value for the white plate adjustment.
4687 2 Result
Displays the current value of the white plate adjustment.
If SP4-428 has not been done, this value is "0".
4690 White Peek Init
4658 1 EVEN
[0 to 255 / - / 1 /step]
Displays the white offset value of the pre-offset adjustment
in the SBU.
4658 2 ODD
4658 3 RED
4658 4 GREEN
4658 5 BLUE
4693 Black Ave Init
4658 1 EVEN [0 to 255 / - / 1 /step]
Displays the black offset value of the pre-offset
adjustment in the SBU.
4658 2 ODD
5. Service Tables
146
