5.7.3 Bar Chart
Click or tap to enter the display interface.
Figure 5.57 Display Interface
1. Enable the graph
Click or tap the ON/OFF tab for the Switch menu to enable or disable the graph
display.
2. Select the graph type
Click or tap the drop-down list of
Chart Type to select "BarChart". Then the
following interface is displayed.
Front Panel Operation
DM858 Series User Guide
88
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
