To Measure AC Voltage
•
To Measure DC Current
•
To Measure AC Current
•
To Measure Resistance
•
To Measure Capacitance
•
To Test Continuity
•
To Check Diode
•
To Measure Frequency/Period
•
Any Sensor Measurement
5.3.1 To Measure DC Voltage
The instrument can measure up to 1,000 V DC voltage. The following section
introduces the connection methods and measurement methods of DC voltage.
NOTE
DCV measurement is selected by default.
Operation Procedures:
1. To enter the DC voltage measurement interface, perform either one of the
following two operations.
- Press on the front panel;
- Click or tap the main measurement item shown at the left part of the main
display area. The measurement items are displayed. Click or tap to select
to enter the DC voltage interface.
Front Panel Operation
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DM858 Series User Guide
33
