Table 8.3 Analog Filter Error in DCV Measurement
Range Reading Speed Additional Analog Filter Error
100 mV
Slow 10 μV
Medium 20 μV
Fast 20 μV
1 V
Slow 15 μV
Medium 20 μV
Fast 20 μV
10 V
Slow 0.8 mV
Medium 1 mV
Fast 1 mV
Table 8.4 Analog Filter Error in DCI Measurement
Range Reading Speed Additional Analog Filter Error
100 μA
Slow 0.002% of range
Medium 0.005% of range
Fast 0.005% of range
10 mA, 1 A
Slow 0.040% of range
Medium 0.060% of range
Fast 0.080% of range
100 mA
Slow 0.004% of range
Medium 0.010% of range
Fast 0.010% of range
10A
Slow 0.008% of range
Medium 0.010% of range
