Rigol DM858 - Figure 5.5 DC Current Measurement Interface

Operation Procedures:
1. To enter the DC current measurement interface, perform either one of the
following two operations.
- Press on the front panel;
- Click or tap the main measurement item shown at the left part of the main
display area. The measurement items are displayed. Click or tap to select
to enter the DC current interface.
Figure 5.5 DC Current Measurement Interface
2. Connect red lead to terminal Input-I and black lead to terminal Input-LO, as shown
in the figure below.
Front Panel Operation
