Figure 5.21 Frequency Measurement Interface
2. Connect red lead to terminal Input-HI and black lead to terminal Input-LO, as
shown in the figure below.
Figure 5.22 Frequency Measurement Connection Diagram
3. Click or tap to set the range of the frequency measurement.
Table 5.10 Frequency Measurement Settings
Parameter Description
Range Auto, 100 mV, 1 V, 10V, 100 V, 750 V
Front Panel Operation
