The power requirements of the multimeter are DC, 12 V, 3 A. Please use the power
adaptor provided in the accessories to connect the multimeter to the AC power
source (100 V to 240 V, 50 Hz to 60 Hz).
6. Security Lock Hole
You can lock the instrument to a fixed location by using the security lock (please
purchase it by yourself) via the lock hole.
7. Ground Terminal
Connects with the instrument chassis and ground lead (power cord ground
terminal), which is in the grounded state.
8. Mounting Screw Holes (VESA 100 x 100)
Mounts the multimeter to the bracket with the screws.
4.4.3 User Interface Overview
3
5
4
9 10
11
12
13
1
2
7
8
6
Figure 4.7 User Interface (Single Display)
Quick Start
DM858 Series User Guide
