Basic Measurement Function
DCV DCI ACV ACI FREQ PERIOD 2WR 4WR Cap
ACI
Avail
able
FREQ
Avail
able
Avail
able
Availa
ble
PERIOD
Avail
able
Avail
able
Available
2WR
Availa
ble
4WR
Availa
ble
Cap
Avail
able
Remarks:
1. If the measurement type for the basic measurement and 2ND measurement is the
same:
- The measurement data are updated synchronously in both the main display
area and the secondary display area.
- If the math operations are adopted for the basic measurement types, then the
operation results are displayed in the main display area and the measurement
values before the operation are displayed in the secondary display area. For
details, refer to
User Interface Overview
.
2. If the measurement type for the basic measurement and 2ND measurement is
different:
- The two types of measurements are carried out alternatively. The measurement
data in the main display area and the secondary display area are updated
respectively.
- If math operations such as Stat, Limit, dBm, and dB are adopted and Relative
operation is disabled for the basic measurement types, then the measurement
values for the main measurement types are displayed in the main display area
and the measurement values for the secondary measurement types are
displayed in the secondary display area.
- If the math operations such as Stat, Limit, dBm, and dB are adopted and
Relative operation is enabled for the basic measurement types, then the
Relative operation results are displayed in the main display area and the
Front Panel Operation
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DM858 Series User Guide
69
