Components
Components
The analyzer is equipped with an internal computer system and proprietary software
for data recording and processing. At the rear, several ports are available for
connection to network, printer, etc.
Figure 3-2 Main components
A USB port G USB ports for printer, mouse, barcode
reader, and keyboard
M Measurement block
B Pipette cable connection H Mains power socket N Preheating position
C Pipette cable I Monitor O Reagent holder
D Power push-button J Electronic pipette (optional) P Mouse
E USB ports for printer, mouse, barcode
reader, and keyboard
K Sensor cable Q Keyboard
F Monitor port L Measuring position for test cells R Network connection
AB C D E F G H
I
J
K
L
M
N
O
P
Q
R
