Roland Fantom XR User Manual

252
MIDI Implementation
● Data Transmission
❍ Data set 1 DT1 (12H)
Status Data byte Status
F0H 41H, dev, 00H, 6BH, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... ffH, sum
Byte Explanation
F0H Exclusive status
41H ID number (Roland)
dev Device ID (dev: 00H - 1FH, 7FH)
00H Model ID #1 (Fantom-XR)
6BH Model ID #2 (Fantom-XR)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of the data to be
sent
bbH Address: upper middle byte of the starting address of the data
to be sent
ccH Address: lower middle byte of the starting address of the data
to be sent
ddH Address LSB: lower byte of the starting address of the data to be
sent.
eeH Data: the actual data to be sent. Multiple bytes of data are
transmitted in order starting from the address.
: :
ffH Data
sum Checksum
F7H EOX (End Of Exclusive)
* The amount of data that can be transmitted at one time depends on the type of data, and
data will be transmitted from the specified starting address and size. Refer to the address
and size given in Parameter Address Map (p. 252).
* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each
packet will be sent at an interval of about 20 ms.
3. Parameter Address Map
* Transmission of “#” marked address is diviedd to some packets. For example, ABH in
hexadecimal notation will be divied to 0AH and 0BH, and is sent/received in this order.
* “<*>” marked adddress or parameters are ignored when the Fantom-XR received them.
1. Fantom-XR (ModelID = 00H 6BH)
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 01 00 00 00 | Setup |
|—————————————+————————————————————————————————————————————————————————————————|
| 02 00 00 00 | System |
|—————————————+————————————————————————————————————————————————————————————————|
| 10 00 00 00 | Temporary Performance |
| 11 00 00 00 | Temporary Patch/Rhythm (Performance Mode Part 1) |
| 11 20 00 00 | Temporary Patch/Rhythm (Performance Mode Part 2) |
| : | |
| 14 60 00 00 | Temporary Patch/Rhythm (Performance Mode Part 16) |
| 1E 00 00 00 | Temporary Rhythm Pattern |
| 1E 01 00 00 | Temporary Arpeggio (Performance Mode) |
| 1E 02 00 00 | Temporary Chord (Performance Mode) |
| 1E 03 00 00 | Temporary Rhythm Group (Performance Mode) |
| 1E 11 00 00 | Temporary Arpeggio (Patch Mode) |
| 1E 12 00 00 | Temporary Chord (Patch Mode) |
| 1E 13 00 00 | Temporary Rhythm Group (Patch Mode) |
| 1F 00 00 00 | Temporary Patch/Rhythm (Patch Mode) |
+——————————————————————————————————————————————————————————————————————————————+
❍ System
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | System Common |
| 00 02 00 | System Mastering |
| 00 03 00 | System External Input |
+——————————————————————————————————————————————————————————————————————————————+
❍ Temporary Patch/Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Temporary Patch |
| 10 00 00 | Temporary Rhythm |
+——————————————————————————————————————————————————————————————————————————————+
❍ Performance
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Performance Common |
| 00 02 00 | Performance Common MFX1 |
| 00 04 00 | Performance Common Chorus |
| 00 06 00 | Performance Common Reverb |
| 00 08 00 | Performance Common MFX2 |
| 00 0A 00 | Performance Common MFX3 |
| 00 10 00 | Performance MIDI (Channel 1) |
| 00 11 00 | Performance MIDI (Channel 2) |
| : | |
| 00 1F 00 | Performance MIDI (Channel 16) |
| 00 20 00 | Performance Part (Part 1) |
| 00 21 00 | Performance Part (Part 2) |
| : | |
| 00 2F 00 | Performance Part (Part 16) |
| 00 60 00 | Performance Controller |
+——————————————————————————————————————————————————————————————————————————————+
❍ Patch
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Patch Common |
| 00 02 00 | Patch Common MFX |
| 00 04 00 | Patch Common Chorus |
| 00 06 00 | Patch Common Reverb |
| 00 10 00 | Patch TMT (Tone Mix Table) |
| 00 20 00 | Patch Tone (Tone 1) |
| 00 22 00 | Patch Tone (Tone 2) |
| 00 24 00 | Patch Tone (Tone 3) |
| 00 26 00 | Patch Tone (Tone 4) |
+——————————————————————————————————————————————————————————————————————————————+
❍ Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Rhythm Common |
| 00 02 00 | Rhythm Common MFX |
| 00 04 00 | Rhythm Common Chorus |
| 00 06 00 | Rhythm Common Reverb |
| 00 10 00 | Rhythm Tone (Key # 21) |
| 00 12 00 | Rhythm Tone (Key # 22) |
| : | |
| 01 3E 00 | Rhythm Tone (Key # 108) |
+——————————————————————————————————————————————————————————————————————————————+
❍ Arpeggio
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Arpeggio Common |
| 00 10 00 | Arpeggio Pattern (Note 1) |
| 00 11 00 | Arpeggio Pattern (Note 2) |
| : | |
| 00 1F 00 | Arpeggio Pattern (Note 16) |
+——————————————————————————————————————————————————————————————————————————————+
❍ Chord
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Chord Pattern |
+——————————————————————————————————————————————————————————————————————————————+
