Roland Fantom XR User Manual

262
MIDI Implementation
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 13 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 17 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 23 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 27 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 33 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 37 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 43 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 47 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 53 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Patch TMT (Tone Mix Table)
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 aaaa | Structure Type 1 & 2 (0 - 9) |
| | | 1 - 10 |
| 00 01 | 0000 00aa | Booster 1 & 2 (0 - 3) |
| | | 0, +6, +12, +18 [dB] |
| 00 02 | 0000 aaaa | Structure Type 3 & 4 (0 - 9) |
| | | 1 - 10 |
| 00 03 | 0000 00aa | Booster 3 & 4 (0 - 3) |
| | | 0, +6, +12, +18 [dB] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 04 | 0000 00aa | TMT Velocity Control (0 - 3) |
| | | OFF, ON, RANDOM, CYCLE |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 05 | 0000 000a | TMT1 Tone Switch (0 - 1) |
| | | OFF, ON |
| 00 06 | 0aaa aaaa | TMT1 Keyboard Range Lower (0 - 127) |
| | | C-1 - UPPER |
| 00 07 | 0aaa aaaa | TMT1 Keyboard Range Upper (0 - 127) |
| | | LOWER - G9 |
| 00 08 | 0aaa aaaa | TMT1 Keyboard Fade Width Lower (0 - 127) |
| 00 09 | 0aaa aaaa | TMT1 Keyboard Fade Width Upper (0 - 127) |
| 00 0A | 0aaa aaaa | TMT1 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 0B | 0aaa aaaa | TMT1 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 0C | 0aaa aaaa | TMT1 Velocity Fade Width Lower (0 - 127) |
| 00 0D | 0aaa aaaa | TMT1 Velocity Fade Width Upper (0 - 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0E | 0000 000a | TMT2 Tone Switch (0 - 1) |
| | | OFF, ON |
| 00 0F | 0aaa aaaa | TMT2 Keyboard Range Lower (0 - 127) |
| | | C-1 - UPPER |
| 00 10 | 0aaa aaaa | TMT2 Keyboard Range Upper (0 - 127) |
| | | LOWER - G9 |
| 00 11 | 0aaa aaaa | TMT2 Keyboard Fade Width Lower (0 - 127) |
| 00 12 | 0aaa aaaa | TMT2 Keyboard Fade Width Upper (0 - 127) |
| 00 13 | 0aaa aaaa | TMT2 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 14 | 0aaa aaaa | TMT2 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 15 | 0aaa aaaa | TMT2 Velocity Fade Width Lower (0 - 127) |
| 00 16 | 0aaa aaaa | TMT2 Velocity Fade Width Upper (0 - 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 17 | 0000 000a | TMT3 Tone Switch (0 - 1) |
| | | OFF, ON |
| 00 18 | 0aaa aaaa | TMT3 Keyboard Range Lower (0 - 127) |
| | | C-1 - UPPER |
| 00 19 | 0aaa aaaa | TMT3 Keyboard Range Upper (0 - 127) |
| | | LOWER - G9 |
| 00 1A | 0aaa aaaa | TMT3 Keyboard Fade Width Lower (0 - 127) |
| 00 1B | 0aaa aaaa | TMT3 Keyboard Fade Width Upper (0 - 127) |
| 00 1C | 0aaa aaaa | TMT3 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 1D | 0aaa aaaa | TMT3 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 1E | 0aaa aaaa | TMT3 Velocity Fade Width Lower (0 - 127) |
| 00 1F | 0aaa aaaa | TMT3 Velocity Fade Width Upper (0 - 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 20 | 0000 000a | TMT4 Tone Switch (0 - 1) |
| | | OFF, ON |
| 00 21 | 0aaa aaaa | TMT4 Keyboard Range Lower (0 - 127) |
| | | C-1 - UPPER |
| 00 22 | 0aaa aaaa | TMT4 Keyboard Range Upper (0 - 127) |
| | | LOWER - G9 |
| 00 23 | 0aaa aaaa | TMT4 Keyboard Fade Width Lower (0 - 127) |
| 00 24 | 0aaa aaaa | TMT4 Keyboard Fade Width Upper (0 - 127) |
| 00 25 | 0aaa aaaa | TMT4 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 26 | 0aaa aaaa | TMT4 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 27 | 0aaa aaaa | TMT4 Velocity Fade Width Lower (0 - 127) |
| 00 28 | 0aaa aaaa | TMT4 Velocity Fade Width Upper (0 - 127) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 29 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Patch Tone
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Tone Level (0 - 127) |
| 00 01 | 0aaa aaaa | Tone Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 02 | 0aaa aaaa | Tone Fine Tune (14 - 114) |
| | | -50 - +50 |
| 00 03 | 000a aaaa | Tone Random Pitch Depth (0 - 30) |
| | | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
| | | 10, 20, 30, 40, 50, 60, 70, 80, |
| | | 90, 100, 200, 300, 400, 500, |
| | | 600, 700, 800, 900, 1000, 1100, |
| | | 1200 |
| 00 04 | 0aaa aaaa | Tone Pan (0 - 127) |
| | | L64 - 63R |
| 00 05 | 000a aaaa | Tone Pan Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 06 | 00aa aaaa | Tone Random Pan Depth (0 - 63) |
| 00 07 | 0aaa aaaa | Tone Alternate Pan Depth (1 - 127) |
| | | L63 - 63R |
| 00 08 | 0000 000a | Tone Env Mode (0 - 1) |
| | | NO-SUS, SUSTAIN |
| 00 09 | 0000 00aa | Tone Delay Mode (0 - 3) |
| | | NORMAL, HOLD, KEY-OFF-NORMAL, |
| | | KEY-OFF-DECAY |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | Tone Delay Time (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0aaa aaaa | Tone Dry Send Level (0 - 127) |
| 00 0D | 0aaa aaaa | Tone Chorus Send Level (MFX) (0 - 127) |
| 00 0E | 0aaa aaaa | Tone Reverb Send Level (MFX) (0 - 127) |
| 00 0F | 0aaa aaaa | Tone Chorus Send Level (non MFX) (0 - 127) |
| 00 10 | 0aaa aaaa | Tone Reverb Send Level (non MFX) (0 - 127) |
| 00 11 | 0000 aaaa | Tone Output Assign (0 - 12) |
| | | MFX, A, B, ---, ---, |
| | | 1, 2, 3, 4, ---, ---, ---, --- |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 12 | 0000 000a | Tone Receive Bender (0 - 1) |
| | | OFF, ON |
| 00 13 | 0000 000a | Tone Receive Expression (0 - 1) |
| | | OFF, ON |
| 00 14 | 0000 000a | Tone Receive Hold-1 (0 - 1) |
| | | OFF, ON |
| 00 15 | 0000 000a | Tone Receive Pan Mode (0 - 1) |
| | | CONTINUOUS, KEY-ON |
| 00 16 | 0000 000a | Tone Redamper Switch (0 - 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 17 | 0000 00aa | Tone Control 1 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 18 | 0000 00aa | Tone Control 1 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 19 | 0000 00aa | Tone Control 1 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1A | 0000 00aa | Tone Control 1 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1B | 0000 00aa | Tone Control 2 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1C | 0000 00aa | Tone Control 2 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1D | 0000 00aa | Tone Control 2 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1E | 0000 00aa | Tone Control 2 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1F | 0000 00aa | Tone Control 3 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 20 | 0000 00aa | Tone Control 3 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 21 | 0000 00aa | Tone Control 3 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 22 | 0000 00aa | Tone Control 3 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 23 | 0000 00aa | Tone Control 4 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 24 | 0000 00aa | Tone Control 4 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 25 | 0000 00aa | Tone Control 4 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 26 | 0000 00aa | Tone Control 4 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 27 | 0000 00aa | Wave Group Type (0 - 3) |
| | | INT, SRX, SAMPLE, MULTISAMPLE |
|# 00 28 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 30 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 00 34 | 0000 00aa | Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
| 00 35 | 0000 000a | Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 00 36 | 0000 00aa | Wave FXM Color (0 - 3) |
Fantom-XR_r_e.book 262 ページ ２００６年４月４日 火曜日 午前１０時１４分

Roland Fantom XR Specifications

General

Polyphony	128 voices
Multitimbral	16 parts
Wave Memory	128 MB (16-bit linear equivalent)
Display	240 x 64 dots backlit LCD
MIDI	In, Out, Thru
Storage	SmartMedia card slot
Expansion Slots	4 x SRX
Effects	Chorus: 3 types; Reverb: 5 types
Sampling	Yes
USB	Yes (MIDI)
Audio Outputs	4 (L/Mono, R, 3, 4)
Audio Inputs	2 (L/Mono, R)
