Roland Fantom XR User Manual

263
MIDI Implementation
| | | 1 - 4 |
| 00 37 | 000a aaaa | Wave FXM Depth (0 - 16) |
| 00 38 | 0000 000a | Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 00 39 | 00aa aaaa | Wave Pitch Keyfollow (44 - 84) |
| | | -200 - +200 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 3A | 000a aaaa | Pitch Env Depth (52 - 76) |
| | | -12 - +12 |
| 00 3B | 0aaa aaaa | Pitch Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3C | 0aaa aaaa | Pitch Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0aaa aaaa | Pitch Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3E | 000a aaaa | Pitch Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 3F | 0aaa aaaa | Pitch Env Time 1 (0 - 127) |
| 00 40 | 0aaa aaaa | Pitch Env Time 2 (0 - 127) |
| 00 41 | 0aaa aaaa | Pitch Env Time 3 (0 - 127) |
| 00 42 | 0aaa aaaa | Pitch Env Time 4 (0 - 127) |
| 00 43 | 0aaa aaaa | Pitch Env Level 0 (1 - 127) |
| | | -63 - +63 |
| 00 44 | 0aaa aaaa | Pitch Env Level 1 (1 - 127) |
| | | -63 - +63 |
| 00 45 | 0aaa aaaa | Pitch Env Level 2 (1 - 127) |
| | | -63 - +63 |
| 00 46 | 0aaa aaaa | Pitch Env Level 3 (1 - 127) |
| | | -63 - +63 |
| 00 47 | 0aaa aaaa | Pitch Env Level 4 (1 - 127) |
| | | -63 - +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 48 | 0000 0aaa | TVF Filter Type (0 - 6) |
| | | OFF, LPF, BPF, HPF, PKG, LPF2, |
| | | LPF3 |
| 00 49 | 0aaa aaaa | TVF Cutoff Frequency (0 - 127) |
| 00 4A | 00aa aaaa | TVF Cutoff Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 4B | 0000 0aaa | TVF Cutoff Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 4C | 0aaa aaaa | TVF Cutoff Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4D | 0aaa aaaa | TVF Resonance (0 - 127) |
| 00 4E | 0aaa aaaa | TVF Resonance Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4F | 0aaa aaaa | TVF Env Depth (1 - 127) |
| | | -63 - +63 |
| 00 50 | 0000 0aaa | TVF Env Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 51 | 0aaa aaaa | TVF Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 52 | 0aaa aaaa | TVF Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 53 | 0aaa aaaa | TVF Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 54 | 000a aaaa | TVF Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 55 | 0aaa aaaa | TVF Env Time 1 (0 - 127) |
| 00 56 | 0aaa aaaa | TVF Env Time 2 (0 - 127) |
| 00 57 | 0aaa aaaa | TVF Env Time 3 (0 - 127) |
| 00 58 | 0aaa aaaa | TVF Env Time 4 (0 - 127) |
| 00 59 | 0aaa aaaa | TVF Env Level 0 (0 - 127) |
| 00 5A | 0aaa aaaa | TVF Env Level 1 (0 - 127) |
| 00 5B | 0aaa aaaa | TVF Env Level 2 (0 - 127) |
| 00 5C | 0aaa aaaa | TVF Env Level 3 (0 - 127) |
| 00 5D | 0aaa aaaa | TVF Env Level 4 (0 - 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 5E | 000a aaaa | Bias Level (54 - 74) |
| | | -100 - +100 |
| 00 5F | 0aaa aaaa | Bias Position (0 - 127) |
| | | C-1 - G9 |
| 00 60 | 0000 00aa | Bias Direction (0 - 3) |
| | | LOWER, UPPER, LOWER&UPPER, ALL |
| 00 61 | 0000 0aaa | TVA Level Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 62 | 0aaa aaaa | TVA Level Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 63 | 0aaa aaaa | TVA Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 64 | 0aaa aaaa | TVA Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 65 | 000a aaaa | TVA Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 66 | 0aaa aaaa | TVA Env Time 1 (0 - 127) |
| 00 67 | 0aaa aaaa | TVA Env Time 2 (0 - 127) |
| 00 68 | 0aaa aaaa | TVA Env Time 3 (0 - 127) |
| 00 69 | 0aaa aaaa | TVA Env Time 4 (0 - 127) |
| 00 6A | 0aaa aaaa | TVA Env Level 1 (0 - 127) |
| 00 6B | 0aaa aaaa | TVA Env Level 2 (0 - 127) |
| 00 6C | 0aaa aaaa | TVA Env Level 3 (0 - 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 6D | 0000 aaaa | LFO1 Waveform (0 - 12) |
| | | SIN, TRI, SAW-UP, SAW-DW, SQR, |
| | | RND, BEND-UP, BEND-DW, TRP, S&H, |
| | | CHS, VSIN, STEP |
|# 00 6E | 0000 aaaa | |
| | 0000 bbbb | LFO1 Rate (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 70 | 0000 0aaa | LFO1 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 71 | 0aaa aaaa | LFO1 Rate Detune (0 - 127) |
| 00 72 | 0aaa aaaa | LFO1 Delay Time (0 - 127) |
| 00 73 | 000a aaaa | LFO1 Delay Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 74 | 0000 00aa | LFO1 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 75 | 0aaa aaaa | LFO1 Fade Time (0 - 127) |
| 00 76 | 0000 000a | LFO1 Key Trigger (0 - 1) |
| | | OFF, ON |
| 00 77 | 0aaa aaaa | LFO1 Pitch Depth (1 - 127) |
| | | -63 - +63 |
| 00 78 | 0aaa aaaa | LFO1 TVF Depth (1 - 127) |
| | | -63 - +63 |
| 00 79 | 0aaa aaaa | LFO1 TVA Depth (1 - 127) |
| | | -63 - +63 |
| 00 7A | 0aaa aaaa | LFO1 Pan Depth (1 - 127) |
| | | -63 - +63 |
| 00 7B | 0000 aaaa | LFO2 Waveform (0 - 12) |
| | | SIN, TRI, SAW-UP, SAW-DW, SQR, |
| | | RND, BEND-UP, BEND-DW, TRP, S&H, |
| | | CHS, VSIN, STEP |
|# 00 7C | 0000 aaaa | |
| | 0000 bbbb | LFO2 Rate (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 7E | 0000 0aaa | LFO2 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 7F | 0aaa aaaa | LFO2 Rate Detune (0 - 127) |
| 01 00 | 0aaa aaaa | LFO2 Delay Time (0 - 127) |
| 01 01 | 000a aaaa | LFO2 Delay Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 01 02 | 0000 00aa | LFO2 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 01 03 | 0aaa aaaa | LFO2 Fade Time (0 - 127) |
| 01 04 | 0000 000a | LFO2 Key Trigger (0 - 1) |
| | | OFF, ON |
| 01 05 | 0aaa aaaa | LFO2 Pitch Depth (1 - 127) |
| | | -63 - +63 |
| 01 06 | 0aaa aaaa | LFO2 TVF Depth (1 - 127) |
| | | -63 - +63 |
| 01 07 | 0aaa aaaa | LFO2 TVA Depth (1 - 127) |
| | | -63 - +63 |
| 01 08 | 0aaa aaaa | LFO2 Pan Depth (1 - 127) |
| | | -63 - +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 01 09 | 0000 aaaa | LFO Step Type (0 - 1) |
| 01 0A | 0aaa aaaa | LFO Step1 (28 - 100) |
| | | -36 - +36 |
| 01 0B | 0aaa aaaa | LFO Step2 (28 - 100) |
| | | -36 - +36 |
| 01 0C | 0aaa aaaa | LFO Step3 (28 - 100) |
| | | -36 - +36 |
| 01 0D | 0aaa aaaa | LFO Step4 (28 - 100) |
| | | -36 - +36 |
| 01 0E | 0aaa aaaa | LFO Step5 (28 - 100) |
| | | -36 - +36 |
| 01 0F | 0aaa aaaa | LFO Step6 (28 - 100) |
| | | -36 - +36 |
| 01 10 | 0aaa aaaa | LFO Step7 (28 - 100) |
| | | -36 - +36 |
| 01 11 | 0aaa aaaa | LFO Step8 (28 - 100) |
| | | -36 - +36 |
| 01 12 | 0aaa aaaa | LFO Step9 (28 - 100) |
| | | -36 - +36 |
| 01 13 | 0aaa aaaa | LFO Step10 (28 - 100) |
| | | -36 - +36 |
| 01 14 | 0aaa aaaa | LFO Step11 (28 - 100) |
| | | -36 - +36 |
| 01 15 | 0aaa aaaa | LFO Step12 (28 - 100) |
| | | -36 - +36 |
| 01 16 | 0aaa aaaa | LFO Step13 (28 - 100) |
| | | -36 - +36 |
| 01 17 | 0aaa aaaa | LFO Step14 (28 - 100) |
| | | -36 - +36 |
| 01 18 | 0aaa aaaa | LFO Step15 (28 - 100) |
| | | -36 - +36 |
| 01 19 | 0aaa aaaa | LFO Step16 (28 - 100) |
| | | -36 - +36 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 01 1A | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Rhythm Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Rhythm Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 01 | 0aaa aaaa | Rhythm Name 2 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 02 | 0aaa aaaa | Rhythm Name 3 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 03 | 0aaa aaaa | Rhythm Name 4 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 04 | 0aaa aaaa | Rhythm Name 5 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 05 | 0aaa aaaa | Rhythm Name 6 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 06 | 0aaa aaaa | Rhythm Name 7 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 07 | 0aaa aaaa | Rhythm Name 8 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 08 | 0aaa aaaa | Rhythm Name 9 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 09 | 0aaa aaaa | Rhythm Name 10 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0A | 0aaa aaaa | Rhythm Name 11 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0B | 0aaa aaaa | Rhythm Name 12 (32 - 127) |
| | | 32 - 127 [ASCII] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0aaa aaaa | Rhythm Level (0 - 127) |
| 00 0D | 0000 000a | (reserve) <*> |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | (reserve) <*> |
| 00 10 | 0000 000a | (reserve) <*> |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 11 | 0000 aaaa | Rhythm Output Assign (0 - 13) |
| | | MFX, A, B, ---, ---, |
| | | 1, 2, 3, 4, ---, ---, ---, ---, |
| | | TONE |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 12 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Rhythm Common MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | MFX Type (0 - 127) |
| 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) |
| 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) |
| 00 04 | 0000 00aa | MFX Output Assign (0 - 3) |
| | | A, B, ---, --- |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 05 | 0aaa aaaa | MFX Control 1 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 06 | 0aaa aaaa | MFX Control 1 Sens (1 - 127) |
| | | -63 - +63 |
| 00 07 | 0aaa aaaa | MFX Control 2 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 08 | 0aaa aaaa | MFX Control 2 Sens (1 - 127) |
| | | -63 - +63 |
| 00 09 | 0aaa aaaa | MFX Control 3 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0A | 0aaa aaaa | MFX Control 3 Sens (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | MFX Control 4 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0C | 0aaa aaaa | MFX Control 4 Sens (1 - 127) |
| | | -63 - +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) |
| | | OFF, 1 - 16 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
Fantom-XR_r_e.book 263 ページ ２００６年４月４日 火曜日 午前１０時１４分

Roland Fantom XR Specifications

General

Polyphony	128 voices
Multitimbral	16 parts
Wave Memory	128 MB (16-bit linear equivalent)
Display	240 x 64 dots backlit LCD
MIDI	In, Out, Thru
Storage	SmartMedia card slot
Expansion Slots	4 x SRX
Effects	Chorus: 3 types; Reverb: 5 types
Sampling	Yes
USB	Yes (MIDI)
Audio Outputs	4 (L/Mono, R, 3, 4)
Audio Inputs	2 (L/Mono, R)
