SATO M-10e TT/DT Printers Service Manual
Section 2. Configuration
External Signal Type Selection (DSW3-6, DSW3-7):
This setting selects the both the polarity and signal type (level or pulse) of the external
print synchronizing signal. See Section 3 for a definition of signal types.
EXT Print Start Signal Selection (DSW3-5):
This selection allows an external device to initiate a label print for synchronization with the
applicator. See Section 3: Interface Specifications for a description of the signal level and
requirements. When DSW3-5 is On, the unit is in the Continuous print mode, Backfeed is
disabled and External Signals are ignored.
123 4 56 7 8
ON
OFF
DSW3
DSW3-5 SETTING
Off Disabled
On Enabled
123 4 56 7 8
ON
OFF
DSW3
123 4 56 7 8
ON
OFF
DSW3
DSW3-8 SETTING
Off Disabled
On Enabled
Repeat Print via External Signal (DSW3-8):
This setting allows an applicator or other device to reprint the last label of the print job.
See Section 3: Interface Specifications for a description of the signal requirements.
DSW3-6 DSW3-7 SETTING
Off Off Type 4
Off On Type 3
On Off Type 2
On On Type 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
