SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
2-14
Section 2. Configuration
LCD Panel —Advanced Mode
Zero Slash
This setting determines if a zero is printed with a slash or without a slash. This setting can also
be controlled via software commands. When YES is selected, the printer internal fonts will have
a slash through the center of the zero character.
STEP PROCEDURE
1. Use the keys to step the cursor to either YES or NO.
2. Once the correct setting is selected, press ENTER to accept the setting
and advance to the Auto Online display.
zero slash
Yes No
Auto Online
This setting determines the mode in which the printer powers up. If YES is selected, the
printer powers up in the ONLINE Mode and is ready to print. If NO is selected, the printer
powers up in the OFFLINE Mode and must be manually placed in the ONLINE Mode by
pressing the ENTER key before it is ready to print.
STEP PROCEDURE
1. Use the keys to step the cursor to either YES or NO.
2. Once the correct setting is selected, press ENTER to accept the setting
and advance to the Print Offset display.
auto online
Yes No
Print Offset
Since the printer move the label in discrete steps equal to the size of the print dot, the units of
measure for Vertical and Horizontal Offset distance is dots.
Vertical Offset
is the distance down from the leading edge in dots (the edge of the label that
comes out of the printer first) to the first vertical print position. A positive setting moves the
label edge out of the printer while making it negative moves it back into the printer. The
maximum value that can be set is 3600 dots.
print offset
v:+0000 h:+0000

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
