SATO M-10e TT/DT Printers Service Manual
Section 2. Configuration
STEP PROCEDURE
1. Record all current dip switch positions, then place all switches in the
OFF or down position.
2. Place the DSW2-6 in the ON or up position.
3. Turn ON the power switch. The following screens will appear.
Waiting for downloading
of program/font data from
the computer.
Display current download
mode in X.
Download completed.
Display the error content
in XXXX
Press the ENTER key to return to the original selection screen.
LCD Panel — Download Mode
flash download
ready
xxxxxxx download
completed
download error
xxxxxxx error
xxxxxxx download
downloading

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
