Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-1
I/O modules PCD1|PCD2
Overview
5
5 Input/output (I/O) modules for PCD1 and PCD2
5.1 General informations
5.1.1 Overview
The summary below shows the available digital and analogue I/O modules, coun-
ters etc. for the PCD2 series:
Type Desig-
nation
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 digital input modules
PCD2.E110 8 I 8 8 inputs 8 ms 24 VDC 5-10
PCD2.E111 8 I 8 8 inputs 0.2 ms 24 VDC
5-10
PCD2.E112 8 I 8 8 inputs 9 ms 12 VDC 5-10
PCD2.E116 8 I 8 8 inputs 0.2 ms 5 VDC 5-10
PCD2.E160 16 I 16 16 inputs 8 ms, connection via
34-pole ribbon connector
24 VDC 5-13
PCD2.E161 16 I 16 16 inputs 0.2 ms, connection via
34-pole ribbon connector
24 VDC 5-13
PCD2.E165 16 I 16 16 inputs 8 ms,
spring terminal connection
24 VDC 5-16
PCD2.E166 16 I 16 16 inputs 0.2 ms,
spring terminal connection
24 VDC 5-16
PCD2 digital input modules, electrically isolated
1
)
PCD2.E500 6 I 6 6 inputs 100 … 240 VAC 5-19
PCD2.E610 8 I 8 8 inputs 10 ms,
electrically isolated
24 VDC 5-21
PCD2.E611 8 I 8 8 inputs 0.2 ms,
electrically isolated
24 VDC 5-21
PCD2.E613 8 I 8 8 inputs 9 ms,
electrically isolated
48 VDC 5-21
PCD2.E616 8 I 8 8 inputs 0.2 ms,
electrically isolated
5 VDC 5-21
PCD2 digital output modules
PCD2.A300 6 O 6 6 outputs 2 A 10 … 32 VDC 5-24
PCD2.A400 8 O 8 8 outputs 0.5 A 5 … 32 VDC 5-26
PCD2.A460 8 O 8 16 outputs 0.5 A, connection via
34-pole ribbon connector
10 … 32 VDC 5-28
PCD2.A465 16 O 16 16 outputs 0.5 A,
spring terminal connection
10 … 32 VDC 5-31
1) galvanic separation of outputs to Saia PCD
®
, the channels themselves are not separated against
each other
